XPL8572 6V 0.6A 超低噪声LDO
-
-
Part NumberXPL8572
-
Vin_min(V)1.2
-
Vin_max(V)6.0
-
Iout_max(A)3
-
Vout(V)0.5~3.3
-
Vdropout(V)0.06
-
IGND30uA
-
FeaturesUltra-Low Noise, Ultra-Low Dropout LDO
-
PackageSOT-23-3/SOT-23-5/DFN 1x4L/DFN 2x2-6L
-
-
• Fast Transient Response
• ±2% Output Accuracy
• 600mA Output Current
• 100nA Disable Current ( by option )
• Wide Operating Input Voltage Range: 1.2V to 6V
• Dropout Voltage: 0.06V at 100mA / VOUT 3.3V
• Support Fixed Output Voltage 0.5V, 0.8V, 1.2V, 1.5V, 1.8V, 2.5V, 2.8V, 3.0V, 3.3V
• Stable with Ceramic or Tantalum Capacitor
• Current Limit Protection
• Over-Temperature Protection
• SOT-23-3 , SOT-23-5 , DFN1x1-4L and DFN2x2-6L Packages Available
